MHS2-16D SMC滑动导轨型2爪型气爪 MHS2系列气爪

 MHS2-16D GRIPPER, 2-FINGER SMC滑动导轨型2爪型气爪 MHS2系列气爪



缸径(mm):16,20,25,32,40,50,63

                                                                                    特长:采用楔形凸轮构造,高度小,重量轻。最适合压入等加外力的作业。  重复精度±0.01mm。


DESCRIPTION

The MHS is the latest in the family of rotary operated parallel style grippers. This compact gripper is available in 10 different bore sizes with choices of 2, 3 and 4 fingers which generate gripping forces up to 1270 N. Pinholes are incorporated as standard, facilitating accurate mounting which is achieved through either body tapped or through-hole mounting. By using a wedge cam construction to attach the fingers to the rotary actuator a more compact design is achieved, as well as high repeatability of 0.01 mm. Auto switches can be simply attached via the standard built-in grooves

  • 2 finger parallel style air gripper
  • Two fingers
  • Bore sizes: 16, 20, 30, 32, 40, 50, 63 *
  • Thirteen different switches in .5mm or 3mm lead wire lengths




Model Bore size (mm) Fluid Operating pressure (MPa) Ambient and fluid temperature (C) Repeatability (mm) Max. operating frequency (c.p.m.) Lubrication Action Effective gripping force (N) at 0.5 MPa Note) Opening/Closing stroke (Both sides) (mm) Mass (g)
External grip Internal grip
MHS2-16D 16 Air 0.2 to 0.6 -10 to 60 ?0.01 120 Not required Double acting 21 23 4 58
图片:


Documents:
 Series Catalog MHS2系列目录

SMC Part Description:
GRIPPER, 2-FINGER SMC滑动导轨型2爪型气爪

SMC Products Line:
ACTUATOR 促动器

SMC Family:
MHS3 GRIPPER, 3-FINGER MHS3系列气爪

SMC Family Code:
GE

SMC Class Description:
16MM MHS3 DBL ACT, AUTO-SW

Weight:
.35104 lb



供应SMC气缸,SMC圆柱形气爪,SMC平行开闭型气爪,MHS2系列气爪,MHS3系列气爪,MHSJ3系列气爪,MHSL3系列气爪,MHS4系列气爪



部分型号如下:

MHS2-16D  MHS2-20D

MHS2-25D  MHS2-32D

MHS2-40D  MHS2-50D

MHS2-63D  MHS3-16D

MHS20-PS  MHS25-PS

MHS3-100D MHS3-125D

MHS3-20D  MHS3-25D

MHS3-32D  MHS3-40D

MHS3-50D  MHS3-63D

MHS3-80D  MHS4-16D

MHS4-20D  MHS4-25D

MHS4-32D  MHS4-40D

MHS4-50D  MHS4-63D

MHS50-PS  MHS63-PS

MHS3-63D-X1739  MHS3-32D-X4239

MHS3-63D-X4327  MHS4-16D-X2543

MHS4-16D-X2671  MHS4-50D-X2221
